CENNETIC HMC450 Horizontal Machining Center

The HMC450 is a horizontal machining center for multi-face box-type parts, using a rotary table to machine four sides plus top in fewer setups.

Direct source factory — no trading-company markup
2-year warranty on all major components
Setup, training and remote diagnostics included

Product details

The HMC450 is a horizontal machining center for multi-face box-type parts, using a rotary table to machine four sides plus top in fewer setups.

Technical specifications

Item	Unit	Spec
Bed	Cast Iron	Resin-sand casting	HT250
	Lubrication Circuit	RGB Electric oiler	Hoval
	Ball Screw	HIWIN (Taiwan)Ball screw	XYZ:3616
	Linear Guideway	HIWIN (Taiwan)Linear guideway	XYZ: RG35(roller)
	Spindle	DANQUAN (Taiwan)Mechanical spindle	BT40-150/8000rpm
	rotary table	Lianshun rotary table	400mm×400mm(5-axis trunnion)
Electrical	Feed-motor type	TaiwanSyntecfeed motor	XY:2.4 kW/11.5 N·m Z:3.9 kW/18.6 N·m C:1.7 kW/8 N·m
Electrical	Spindle motor	TaiwanSyntecSpindle motor	15 kW/70-100 N·m
System	CNC system	TaiwanSyntec	22MA
Tool Change	Pneumatic tool changer	OKADA (Taiwan)Tool Magazine	disc 32 tools
Appearance	Sheet-metal Enclosure	Full enclosure	Ivory + dark grey
Filter		Combined filter	70 kg 22L/min
Chip Conveyor		RuikeChip Conveyor	Chain-type
Accessories	Tool holders & collets	BT40-ER25	6 pcs each
	Hook spanner	1 set
	Tool-holder stand	BT40	1 pcs
	Tool setter	1 pcs
Service	Freight	out-of-province
	Packing	Wooden-crate packing
	Warranty	1 yr

About this model

This Horizontal Machining Center is manufactured by our partner factory in Dongguan, China, and supplied direct by CENNETIC with factory-direct pricing, a standard warranty and remote setup support. Specifications are representative and can be confirmed against your machining requirements before order.
