Machining Centers (Milling-Focused)

CENNETIC W560L High-Efficiency Machining Center

The W560L is a high-efficiency, high-rigidity machining center designed for fast production cycles on steel and cast parts.

Direct source factory — no trading-company markup
2-year warranty on all major components
Setup, training and remote diagnostics included

Product details

The W560L is a high-efficiency, high-rigidity machining center designed for fast production cycles on steel and cast parts.

Technical specifications

Item	Unit	Spec
Bed	Cast Iron	Resin-sand casting	HT250
	Ball Screw	HIWIN (Taiwan)Ball screw	X,Y, Z : C3 grade4012
	Linear Guideway	HIWIN (Taiwan)Roller linear guideway	X,Y, Z:RG45
	Spindle	DANQUAN (Taiwan)Mechanical spindle	center distance560/BT40-8000rpm(2 pcs)
Electrical	Feed-motor type	TaiwanSyntec	X,Y:AM18-3.9 kW/18.6 N·m
	Feed-motor type	TaiwanSyntecservobrake	Z:AM18-3.9 kW/18.6 N·m
	Spindle motor	TaiwanSyntecSpindle motor	S08-M7.5-10B4-0A0 8000rpm/5.5-7.5 kW(2 pcs)
System	CNC system	TaiwanSyntec	220MA-5milling controller
Tool Change	Pneumatic tool changer	OKADA (Taiwan)Disc-type magazine	BT40 24 tools(2 pcs)
Appearance	Sheet-metal Enclosure	Full enclosure	Ivory + dark grey
Lubrication	Electric oiler	RGB electric oiler	Electric oiler
Lighting	Linear work lamp	LED
Chip Conveyor		ChienKuan	Chip conveyor (scraper)
Accessories	Tool holders / collets	BT40-ER32-70L	per machine, each20 pcs
	Tools	1 set
	Clamp plates	1 set
	Tool rack	1 pcs
	Manual	incl. USB e-document
Service	Freight	in/out province
	Packing	Dedicated transport
	Warranty	1 yr
	Training	On-site

About this model

This Vertical Machining Center is manufactured by our partner factory in Dongguan, China, and supplied direct by CENNETIC with factory-direct pricing, a standard warranty and remote setup support. Specifications are representative and can be confirmed against your machining requirements before order.
