The Z600L+ is a 5-axis drilling and tapping center that adds an RDDS200 direct-drive rotary table to a high-speed vertical platform, enabling angled hole-making and 5-sided contouring of small-to-medium parts in a single setup.
Technical specifications
| Item | Unit | Spec |
|---|---|---|
| X/Y/Ztravel | mm | 600*450*330 |
| Worktable Size | mm | 700*420 |
| Max. Worktable Load | kg | 250 |
| Spindle center to column guideway | mm | 464 |
| Spindle nose to worktable | mm | 300-630 |
| T-slot size | mm | 14T*3*125 |
| Spindle taper / bore dia. | / | BT30(Φ110) |
| Spindle Speed | r/min | 20000 |
| Rapid traverse (X/Y/Z) | m/min | 36/48 |
| Magazine Capacity | set | BT30-21T“Speedcn”Yitaiflip-typeServo magazine |
| THKC3 gradeBall screw | mm | XY: Φ28*12 Z:Φ32*12 |
| THKC3 gradeBall screw | mm | XY: Φ28*16 Z:Φ32*16 |
| THKC3 Linear guideway (Guideway width/slider qty) | mm | XYZ: 30*2 |
| YizhunSpindle motor | KW | 3.7/24000 rpm |
| Tukofeed motor | KW | 2.9 kW/3000 rpm/18.6 N·m |
| Tukofeed motor | KW | 1.8 kW/3000 rpm/18.6 N·m |
| System | set | RNC N3ME |
| Machine overall dimensions (L×W×H) | mm | 1748*2410*2320 |
| weight | kg | approx. 3500 |
Equipment
Standard equipment
- Bed — Cast Iron — Resin-sand casting (ductile ironH300)
- Bed — Lubrication Circuit — Automatic (Hoval)
- Bed — Ball Screw — HIWIN (Taiwan)Ball screw (XY:28*12/16 Z:32*12/16)
- Bed — Linear Guideway — HIWIN (Taiwan)Linear guideway (ball30)
- Bed — Spindle — Speedcn (direct-driveBT30 20000rpm)
- Electrical — Feed-motor type — Tuko (X/Y 1.8 kW/3000 rpm/11.5 N·m)
- Electrical — Feed-motor type — Tuko (Z: 2.9 kW/3000LFN /18.6 N·m)
- Electrical — Spindle motor — YizhunServo spindle motor (3.7 kW 24000 rpm)
- System — CNC: RNC (Shanghai) (N3ME)
- Tool Change — Pneumatic tool changer — TaiwanYitaiTool Magazine (BT30 21 toolsservoArm-type magazine)
- Appearance — Sheet-metal Enclosure — Full enclosure (Ivory + dark grey)
- Lubrication — Electric oiler — RGB electric oiler (Electric oiler)
- Lighting — Linear work lamp (work light)
- Oil cooler — (ChienKuan)
- Service — Freight — out-of-province
- Service — Packing — Wooden-crate packing
- Service — Warranty — 1 year
- Service — Service — On-site
Optional equipment
- Accessories — Tool holders & collets — BT30-ER32 (10 pcs)
- Accessories — Tool kit (1 set)
- Accessories — Clamp plates (per machine1 set)
- Accessories — Tool rack (1 pcs)
- Accessories — Manual (incl. USB e-document)
About this model
This 5-Axis Machining Center is manufactured by our partner factory in Dongguan, China, and supplied direct by CENNETIC with factory-direct pricing, a standard warranty and remote setup support. Specifications are representative and can be confirmed against your machining requirements before order.
